L-144

L-144

TECHNICAL SPECIFICATIONS:

Power supply: 220-240V AC 50/60Hz

Power consumption: MAX. 720W

LED Quantity: 144 pcs R.G.B.W 36 each

DMX-512-connection: 3-pin XLR

Flash-rate: max. 10 Hz

Dimensions: 63x40x17cm

Weight: 9.1Kg

DMX FUNCTION:

Six DMX channels (P--2):

Channel 1: red from small to big brightness (dimming)
Channel 2: green from small to big brightness (dimming)
Channel 3: blue from small to big brightness (dimming)
Channel 4: speed/strobe

0-15                 off

16-255     strobe and speed adjustments

Channel 5: warm white from small to big brightness (dimming)
Channel 6: master

0-255      master dimmer

Seven DMX channels(P--1):

Channel 1: red from small to big brightness (dimming)
Channel 2: green from small to big brightness (dimming)
Channel 3: blue from small to big brightness (dimming)
Channel 4: warm white from small to big brightness (dimming)
Channel 5: speed/strobe

0-15                 off

16-255     strobe and speed adjustments

Channel 6: mode

0-27        dimmer

28-55      increasing brightness

56-83      decreasing brightness

84-111     decreasing brightness then increasing brightness

112-139    auto color mix

140-167    3-color flash

168-195   7-color flash

196-223    sound1 mode

224-255   Sound2 mode

Channel 7: master

0-255      master dimmer

 Five DMX channels (P--3):

Channel 1: master

0-255      master dimmer

Channel 2: red from small to big brightness (dimming)
Channel 3: green from small to big brightness (dimming)
Channel 4: blue from small to big brightness (dimming)
Channel 5: warm white from small to big brightness (dimming)
Four DMX channels (P--4):

Channel 1: red from small to big brightness (dimming)
Channel 2: green from small to big brightness (dimming)
Channel 3: blue from small to big brightness (dimming)
Channel 4: warm white from small to big brightness (dimming)
